11.1V 7.8Ah 86.58Wh 117186CR Lithium Ion Battery Pack

The 117186CR lithium-ion battery pack delivers a stable 11.1V 7.8Ah output in a compact, lightweight form factor. Built with A-grade cells and a 3S3P configuration, it offers more than 800 charge cycles and reliable performance across a wide temperature range. Its integrated PCM/BMS provides comprehensive protection against overcharge, over-discharge, over-current, and short circuit — making it a safe, maintenance-free power solution for demanding applications.

The pack supports parallel and series connection for flexible system integration, and can be customized in capacity, connectors, and dimensions to meet your specific requirements.

Features:

• Grade A cells — Carefully selected premium cells ensure consistent performance and more than 800 cycle life.
• Comprehensive BMS Protection — Integrated PCM/BMS safeguards against overcharge, over-discharge, over-current, short circuit, and thermal events.
• Higher Power, Lower Weight — Delivers more usable power than equivalent lead-acid batteries at a fraction of the weight.
• Maintenance-Free — No watering, no equalizing, no memory effect. Ready to use with minimal upkeep.
• Flexible Connection — Supports both parallel and series connection for scalable voltage and capacity.
• Customizable — Capacity, connectors, dimensions, and discharge rates can be tailored to your application.

Specifications:

• Name: Lithium ion battery pack
• Model: 117186CR
• Configure: 3S3P
• Nominal Voltage: 11.1V
• Nominal Capacity: 7.8Ah
• Rated Energy: 86.58Wh
• Charging Voltage: 12.6V max
• Charging Current: 2A max
• Charging Method: Constant Current/Constant Voltage (CC/CV)
• Discharging Current: 3A max continuous, 5A peak
• Discharging Cutoff Voltage: 9V
• Cell Type: A-grade NCM li-ion cell
• PCM/BMS: Integrated BMS for protection against overcharge, overdischarge, overcurrent, short circuit, overheat, and cell balancing
• Housing: PVC shrink wrap
• Terminal: Customizable wire leads, connectors
• Dimensions: 75mm x 58mm x 58mm max
• Weight: 0.5kg approx.
• Environment Conditions: Charge: 0~45°C, Discharge: -20~60°C, Storage: -20~40°C, best 20±5°C for long time storage. Humidity: 85% max
• Customization: Modifications or custom designs available

Application Scenarios:

• Portable Electronics: Backup power, portable devices, mobile equipment.
• Industrial Equipment: Industrial controls, instrumentation, low-power machinery.
• Security Systems: Access control, alarm panels, surveillance backup.
• Lighting: Portable LED lighting, emergency lighting.
• Medical Devices: Portable diagnostic tools, patient monitoring equipment.
• Custom OEM Projects: Custom battery packs for specialized applications.

Charging & Safety Guidelines:
Always follow these guidelines for safe operation and maximum cycle life:

• Use only a charger compatible with the charging specifications of the battery.
• Charge at standard current rate for optimal cycle life; max current rate for faster charging.
• Never charge above the maximum charging voltage to avoid overcharge.
• Do not discharge below the discharging cutoff voltage to avoid overdischarge and prevent permanent damage.
• Do not discharge above the current rating. Exceeding these limits may trigger BMS protection or cause permanent damage to the battery cells.
• Operate the battery within the specified environmental conditions (temperature, humidity, and ventilation).
• Keep the battery away from fire, open flames, radiators, and other heat sources.
• Do not expose the battery to direct sunlight for extended periods during operation.
• Store at 20±5°C for extended periods to maximize longevity. Keep humidity below 85% during storage.
• Do not disassemble, puncture, or expose to fire.

Shipping & Handling Instructions:
To ensure safe transport and compliance with international regulations, please note the following:

• The battery can be shipped by air, sea, and ground transport — subject to applicable dangerous goods regulations for lithium batteries.
• UN38.3 Compliant — The battery has been tested and certified in accordance with UN38.3 for safe air and sea transport.
• Package Properly — Use only UN-certified packaging for lithium batteries. Ensure terminals are protected against short circuits and pack securely to prevent movement during transit.
• State of Charge (SoC) — For transport, maintain the battery at ≤30% state of charge as required by IATA and IMDG regulations.
• Labeling — Packages must display the appropriate lithium battery handling labels and include emergency contact information.
• Documentation — Ensure the shipping declaration includes the proper UN number (e.g., UN3480 for lithium-ion batteries) and your dangerous goods transport documents.
• Prohibited Shipments — Damaged, defective, or recalled batteries are strictly prohibited from transport.

Storage & Long-Term Maintenance:
To ensure maximum service life and maintain optimal cell health, please follow these guidelines for extended storage:

• Optimal Temperature — Store the battery at a stable temperature between 15°C and 25°C (ideal: 20±5°C). Avoid exposure to extreme heat, direct sunlight, or freezing conditions.
• Recommended Humidity — Keep storage environment humidity below 85% to prevent moisture ingress and potential damage to the battery cells and BMS components.
• Partial Charge for Storage — For extended storage (longer than 3 months), maintain the battery at approximately 50%–60% state of charge (around the nominal voltage). Do not store fully charged or fully depleted — both conditions accelerate capacity degradation.
• Periodic Maintenance Cycle — For batteries stored over six months or longer, perform at least one full charge/discharge cycle every six months to maintain cell health. This helps recalibrate the BMS, balance the cells, and prevent voltage drift that can lead to capacity loss.
• Inspect Before Use — Before returning a stored battery to service, inspect for any signs of swelling, leakage, or damage. If the battery voltage is below the discharging cutoff voltage, it has been over-discharged and should not be reused.

💡 Why cycle stored lithium batteries? Cells naturally self-discharge over time, and the built-in BMS circuit consumes a small amount of current even when idle. In multi-cell packs, slight variations in self-discharge rates between cells can gradually cause voltage imbalances. A maintenance cycle keeps the cells electrochemically active, balances the pack, and prevents capacity loss or degradation.
